Summit® 24" Dual Zone Wine Cellar

Product Overview

Summit offers a unique selection of built-in capable full-sized wine cellars for convenient wine storage in the home.

The SWC1966B is a 24" wide dual zone wine cellar designed to display your wine collection under the proper conditions. The evenly divided upper zone is reserved for white and sparkling wine, while the lower zone features a warmer temperature range to best preserve reds. It comes with a front-breathing design for built-in installation, with a fully finished black cabinet that also allows freestanding use. Sized just under 27" deep, this unit has a sealed back and right-angle plug for added depth savings. The exterior features a double pane tempered glass door with stainless steel trim. A stainless steel kickplate provides added elegance, while the pro-style handle completes the look. This unit includes a factory installed keyed lock for added security and powerful magnetic gaskets to ensure a proper seal for efficient cooling.

Inside, the SWC1966B includes 13 wooden shelves that slide out 50% for easy loading and unloading. Optimal storage capacity accommodates up to 162 standard 750ml Bordeaux bottles (note: your capacity may vary depending on the bottle style). For wider Burgundy style bottles (typically used for Pinot Noir and Chardonnay), the SWC1966B can hold up to 146 bottles. Two white LED lights positioned at the top of each zone attractively illuminate your collection for a stylish display, while the digital control panel makes it easy to manage the temperature. An internal fan ensures both zones are properly chilled. A charcoal filtration system keeps the interior odor-free. Additional features include an open door alarm and high/low temperature alarm that sound if the unit temperature goes out of range.

With its convenient size, advanced features, and elegant design, the SWC1966B is the perfect addition to any home bar or kitchen seeking full capacity wine storage with a modern presentation.

Built-in capable

Front-breathing design allows the unit to be integrated with minimum clearance for a flush look (fits in spaces sized at 70.75" H x 23.88"W x 28" D)

Digital thermostat

Located inside the unit, the electronic thermostat allows easy temperature adjustment with a display in Celsius or Fahrenheit

Versatile storage

Interior can hold up to 162 standard 750ml Bordeaux style bottles (19 bottles stacked on the upper shelf, 11 bottles per middle 12 shelves, and 11 on the slotted floor). If storing wider Burgundy style bottles (typically used for Pinot Noir or Chardonnay), you can accommodate up to 146 bottles (11 on the upper shelf, 8 on the top shelf of the lower zone, 11 on each of the other 11 shelves, and 6 on the slotted floor)

LED lighting

Two LED lights at the top of each zone provide an attractive and energy-efficient illumination of your collection with a gentle white hue

Wide temperature range

Upper zone: 41-54°F ideal for chilling white and sparkling wine; Lower zone: 54-65°F for holding reds at a warmer temperature

Charcoal filtration system

Helps to purify air for an odor-free interior

Open door alarm

Alerts if unit door is ajar for more than 5 minutes

Sealed back

Flush back allows for a better fit and easier cleanability

100% CFC free

Environmentally friendly design with no ozone-damaging chemicals

Stainless steel trimmed glass door

Provides a full display of the interior, with two levels of glass for added protection

Slide-out wooden shelving

13 shelves slide out 50% for easier loading and optimum capacity

Factory-installed lock

Keyed lock secures both zones (2 keys included)

Stainless steel kickplate

Allows for front ventilation in an elegant design

High/low temperature alarms

Audibly sounds if the interior rises or falls out of recommended range

Magnetic door gasket

Ensures a tight seal for energy savings and improved performance

CARB Compliant

Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Right angle plug

Professional handle

Design allows you to plug the unit in flush against the wall socket with no need to add extra depth

37" long handle in a brushed stainless look offers the perfect finish to your wine cellar

Two temperature zones

Chill white wine in the upper zone while preserving your reds at a warmer temperature below

Even storage

The upper and lower zones are evenly split for a symmetrical look
